Q-Switched ND YAG Laser machine is proven to be the most effective way to remove tattoos, which emits light in a particular way in short and sharp pulses to break down the tattoo pigments. They are absorbed by the pigments within the skin. This light energy is measured in nanometres (nm) and is emitted at wavelength of 532nm,1064nm.
Laser type | ND: yag laser |
Input power | 600W |
Laser power | 300W |
Output system | Handle tool output |
Laser wavelength | 1064nm & 532nm |
Treatment head | Focus head 2 (1064nm&532nm) / Carbon peeling head |
Pulse width | 532nm: 4ns / 1064nm:4.5ns |
Energy | 100-2000mj (1064nm&532nm) |
Frequency | 1-10hz |
Coolant | Distilled water |
Screen | 10.4 inch touch color screen |
Cooling system | Air+water cooling |
Voltage: | 110V±10%, 60Hz / 220V±10%, 50Hz |
Machine weight | 40kg |
Machine size | 400mm*500mm*1100mm |
Package weight | 60kg |
Package size | 690mm*520mm*1240mm |
Utilizing the explosive effect of the Nd: YAG laser, the laser permeate the epidermis into the dermis which includes amount of pigment mass. Since the laser pulses in nanosecond but with super high energy, the shot pigment mass swell quickly and breaks into small pieces, which will be eliminated through metabolic system.
The 1064nm wavelength laser directly acts on the carbon cream, blasting the toner, and the toner absorbs pore oil and dirt. At the same time, the laser can stimulate the dermis to produce a large amount of collagen, thereby achieving the function of shrinking pores and whitening.
Light Weight
Small size and light weight, easy to transport, saving freight costs.
High Performance
Short pulse width(4ns)
High power(940mj）
Long lifespan
Handle Design
Cost-effective laser handle design
Easy To Use
Controllable spot size, easy to operate.
Good Cooling
High power built in water cooling system make the machine can be continuely use.
Color Display
Operation and parameter adjustment with 10.4 inch color TFT touch screen.
Precise
The laser generator is located at the handle position, which is not prone to polarization.
1. 532nm: Red, orange, brown, stronger exfoliation
2. 1064nm: Nlack, blue, deeper penetration Carbon peeling head.
3. Carbon Peeling Head
Skin rejuvenation, skin whitening and resurfacing.
Freckles, Black spot, Age spots, Coffee spots and sun-burn spots.
Pigment of epidermis and derma layer.
Body tattoo, eyebrow tattooand lips line.
Nevus of Ota and birthmark.
(1) Applying a medical facial mask for one week after treatment is suggested.
(2) It is recommended to apply skin-care products to prevent skin pigmenta-tion after treatment.
(3) Avoid sunlight to prevent pigmentation after treatment. Physical sun-screen (such as wearing a mask or taking sun umbrella while going out)shall be conducted after treatment.
(4) The treatment interval is about one month. Recommended treatment times are shown in parameter table. Doctor shall judge whether more treat-ment is needed according to patients' skin conditions.
(5) Avoid spicy foods or seafood within one week after treatment.
